Product Description:
The HMI Display Module is powered by the ST77916 driver chip, which
ensures stable and reliable performance. This driver chip is
specifically designed for use in high-performance display
applications, making it the ideal choice for this display module.
The HMI Display Module operates on a 5V voltage, making it easy to
integrate into a wide range of projects. Whether you're working on
a hobby project or a commercial application, this display module is
sure to meet your needs.
The display size of the HMI Display Module is 1.8Inch. This compact
size, combined with its high-quality display, makes it perfect for
a wide range of applications. The display is designed to provide a
clear and easy-to-read view from any angle, with a viewing angle of
over 60 degrees.
The HMI Display Module is easy to install and use, making it
perfect for a wide range of applications. Whether you're designing
a new product or upgrading an existing one, this display module is
sure to provide the performance and functionality you need.
Features:
- Product Name: HMI Display Module
- Type: TFT
- Size: 1.8Inch
- Operating Voltage: 5V
- Power consumption: 1W
- Product weight: About 50g
The HMI Display Module is a TFT type Monitor Panel Display Unit,
designed for use as a Human Machine Interface Display Module. It
has a compact 1.8Inch size, operates at 5V and has low power
consumption of 1W. The product is lightweight, weighing in at about
50g.
Technical Parameters:
| Product weight | About 50g |
| Module size | 58*58*11(mm) |
| Driver chip | ST77916 |
| SKU | JC3636W518C |
| Operating Voltage | 5V |
| Display color | RGB 262K Color |
| View | >60° |
| Type | TFT |
| Resolution | 360*360((Pixel) |
| Operating temperature | -20℃~70℃ |
Applications:
The JC3636W518C is a compact Monitor Panel Display Unit that is
perfect for a wide range of applications. It is built to withstand
extreme temperature conditions, with a storage temperature range of
-30℃ to 80℃. With only 1W power consumption and an operating
voltage of 5V, it is energy-efficient and cost-effective.
The JC3636W518C boasts a 1.8Inch screen size, providing clear and
vibrant images for easy monitoring and control. Its wide viewing
angle of over 60° ensures that every detail is visible, making it
perfect for use in industrial control systems, home automation, and
medical equipment.
With its superior performance, durability, and versatility, the
JC3636W518C Human Machine Interface Display Module is the perfect
solution for any application that requires a reliable and efficient
monitor panel display unit.
Customization:
Our Human Machine Interface Display Module is designed to operate
in a wide range of temperatures, from -20℃ to 70℃. It can also be
safely stored in temperatures ranging from -30℃ to 80℃. The power
consumption of our display module is only 1W, making it
energy-efficient and cost-effective.
The effective display area of our Human Machine Interface Display
Module is 45.68* 45.68(mm), and it has a resolution of
360*360((Pixel)). Our product can be customized to fit your desired
specifications, ensuring that it meets your unique needs.
Support and Services:
The HMI Display Module product technical support and services
include:
- Installation and setup assistance
- Technical troubleshooting and problem resolution
- Product updates and upgrades
- Product documentation and user manuals
- Training and education on product features and functionality
- Repair and replacement services
- Remote technical support and assistance
Packing and Shipping:
Product Packaging:
- One HMI Display Module
- One set of connecting cables
- User manual and installation guide
- Protective foam padding
Shipping:
- Ships within 2 business days
- Free standard shipping within the US
- International shipping available at an additional cost
- Tracking information provided once item ships
FAQ:
What is the model number of the HMI Display Module?
The model number of the HMI Display Module is JC3636W518C.
Where is the HMI Display Module manufactured?
The HMI Display Module is manufactured in China.
What is the delivery time for the HMI Display Module?
The delivery time for the HMI Display Module is 28 days.
What are the payment terms for the HMI Display Module?
The payment terms for the HMI Display Module are L/C and T/T.
What is the supply ability for the HMI Display Module?
The supply ability for the HMI Display Module is 5000PCS/day.
